160
Thermally broken sliding glass door — the flagship.
Demonstration assembly with semantic components — final Orluti extrusion geometry replaces this model via the documented GLB pipeline. Values marked ‡ await test-report confirmation.
Overview
System 160 is Orluti's flagship thermally broken sliding door. Dual polyamide thermal breaks keep glass edges warm, stainless tandem carriages carry heavy panels on two fingers of effort, and a slim interlock keeps the view almost uninterrupted where two panels meet. An embedded track option and multi-point locking come standard; biometric entry is available for primary entrances.
Dual polyamide thermal breaks
Condensation-free glass edges, even in cold climates.
Stainless tandem carriages
660 lb of glass moves with two fingers, for decades. [CONFIRM PANEL WEIGHT]
Slim interlock sightline
Where two panels meet, almost nothing interrupts the view.
Multi-point locking
Perimeter locking with anti-lift pins; optional face/fingerprint entry on entrance units.
Configurations
O = fixed panel · X = sliding panel, read from exterior. Pocketing versions conceal panels fully within the wall.
The essential configuration for standard openings.
Full flexibility — open from either side.
A moving center panel between fixed glass.
Panels part from the center for a wide clear opening.
Profile & cross-sections
Photographed from production extrusions
Hardware
- Stainless tandem carriages
Sealed stainless-steel roller bearings sized to panel weight.
- Multi-point lock
Perimeter locking points engage on a single motion of the flush pull.
- Recessed pull
Machined recessed pull; exterior keyed cylinder optional.
- Biometric entry (optional)
Face / fingerprint recognition module for primary entrances.
Glazing
- Double insulated glazing
1" insulated glazing units with warm-edge spacers and argon fill. Low-E coatings selected per orientation and climate. [CONFIRM IGU MAKEUP]
- Triple glazing
Triple-pane units for cold climates and passive-grade targets. [CONFIRM AVAILABILITY PER SYSTEM]
- Acoustic laminated
Acoustic PVB interlayers reduce sound transmission by up to 45 dB in tested configurations.
- Laminated / impact
Laminated safety glass for overhead, railing, and impact-rated applications. [CONFIRM IMPACT RATINGS]
Finishes
- Matte Blackpowder coat
- Bronze Anodizedanodized
- Champagneanodized
- Silver Anodizedanodized
- Custom RALcustom
Specifications
System
- Frame depth
- 6-1/4" (160 mm)‡
- Operation
- In-line slider on stainless tandem carriages
- Thermal break
- Dual polyamide struts
- Max panel
- 660 lb · 12 ft tall‡
- Interlock sightline
- 1-3/8"‡
Performance
- U-factor
- 0.28 (Uw 1.2 W/m²K representative)‡
- Acoustic insulation
- Up to 45 dB
- Water penetration
- Class 5
- Wind resistance
- Class 9
- Security
- RC-2 hardware package
‡ Representative values pending confirmation against Orluti test reports — final performance depends on configuration and glazing.
Documents
Documents are issued per system with current tested values — request routes through the quote form so an engineer can match the right revision to your project.
Applications
Spec the 160 into
your next project.
Schedules · plans · DWGs accepted
